 SOG
= Special optical Glass 320
- 500nm |
PX
= Borofloat 330 - 2500nm |
Q
= Far UV Quartz 170 - 2700nm |
I
= Near infra red Quartz 220 3800nm |
 SX
= Far UV - IR Quartz (water free) 170 - 3500nm |
 |
| Starna
Type |
Material
Type |
Path
Length |
Ext
|
Int
|
Nom
Vol |
Polished
|
| Diameter |
Length |
Diameter |
Length |
| No |
Available
|
mm
|
mm
|
mm
|
mm
|
mm
|
ml
|
Windows
|
| 32 |
SOG/PX/Q/I/SX
|
1
|
22
|
3.5
|
19
|
1
|
0.280
|
2
|
| 32 |
SOG/PX/Q/I/SX
|
2
|
22
|
4.5
|
19
|
2
|
0.560
|
2
|
| 32 |
SOG/PX/Q/I/SX
|
5
|
22
|
7.5 |
19
|
5
|
1.400
|
2
|
| 32 |
SOG/PX/Q/I/SX
|
10
|
22
|
12.5
|
19
|
10
|
2.800
|
2
|
| 32 |
SOG/PX/Q/I/SX
|
20
|
22
|
22.5
|
19
|
20
|
5.600
|
2
|
| 32 |
SOG/PX/Q/I/SX
|
50
|
22
|
52.5
|
19
|
50
|
14.100
|
2
|
| 32 |
SOG/PX/Q/I/SX
|
100
|
22
|
102.5
|
19
|
100
|
28.200
|
2
|
|
